12
5. Web Configuration
Before using the Web Configuration for the DWL-810+, please consider the
following:
Factory Default Settings for the DWL-810+
Operating Mode Infrastructure
SSID default
Channel 6
Transmission rates Auto
Encryption No
Administrator password Blank (no password needed)
IP Address mode Static
IP Address 192.168.0.30
IP Subnet 255.255.255.0
username admin (all lower case)
You will need a JavaScript-enabled web-browser such as the Internet
Explorer 6.0 or later, or the Netscape Navigator 6.0 or later.
The computer that you are using for initial configuration must have
an IP Address within the same range as the IP Address of the DWL-
810+. The DWL-810+ has a default IP Address of 192.168.0.30 with a
subnet mask of 255.255.255.0
You will need to assign a Static IP Address to the computer that you are
using to configure the DWL-810+, within the IP Address Range of the
DWL-810+. For example, you can assign a Static IP address of
192.168.0.2 with a subnet mask of 255.255.255.0 (Please refer to the
Appendix section of the Quick Installation Guide.)
