Configuration Menu

Channel: Channel 6 is the default channel. Input a new number if you

want to change the default setting. All devices on the network must be set to

the same channel to communicate on the network.

WEP Encryption: Select Enable Encryption to use WEP (Wired Equivalent

Privacy) on the network. All devices on the network, and the Access Point,

must share the same WEP selection – either Enable or Disable, and they

must share the same WEP key. The WEP key is generated from ASCII or

Hexadecimal entries that are either 64, 128, or 256 bits in length. When

enabling encryption, select the Key Type (ASCII or Hexadecimal) and then

input the appropriate digits or letters. You can create up to 4 keys. Select

the key you wish to use.

Transmission Rate: Select the transmission rate for the network. The

default setting is 1-2-5.5-11-22 (Mbps)

Authentication:

Open System – communicates the key across the network

Shared Key – devices must have identical WEP settings to

communicate

Auto – automatically adjusts to the Authentication mode of the

wireless client

Click Apply if you have made any changes or additions.

Hexadecimal digits consist of the numbers 0-9 and the letters A-F

ASCII (American Standard Code for Information Interchange) is a code

for representing English letters as numbers from 0-127
