32
France 10 13 11 14 4
Canada 1 11 6 24 24
Table 3: Regulatory Domains Specifications
Channel Frequency
1 2412 MHz
2 2417 MHz
3 2422 MHz
4 2427 MHz
5 2432 MHz
6 2437 MHz
7 2442 MHz
8 2447 MHz
9 2452 MHz
10 2457 MHz
11 2462 MHz
12 2467 MHz
13 2472 MHz
Table 4: Frequency List
NOTE: The frequencies listed in the table are at the center of the channel. Each
channel occupies 22MHz, therefore each channel occupies
-11MHz to +11 MHz from the frequency specified.
