Free Space Loss
Attenuation of the electromagnetic wave while propagating through space. This
attenuation is calculated using the following formula:
Free space loss = 32.4 + 20xLog(F
MHz
) + 20xLog(R
Km
)
F is the RF frequency expressed in MHz.
R is the distance between the transmitting and receiving antennas (expressed in
Km).
At 2.4 GHz, this formula is: 100+20xLog(R
Km
)
