D-Link DWL-1800R [53/77] Environmental
![D-Link DWL-1800R [53/77] Environmental](/views2/1044813/page53/bg35.png)
48
5.9 Mechanical Dimensions
Outdoor Unit
30 x 30 x 7.2 cm
12 x 4.7 x 2 in
Indoor Unit
15.4 x 8.4 x 5.6 cm
6.1 x 3.3 x 2.2 in
5.10 Environmental
Operating Temperature
Indoor unit: 0?C to 40?C
Outdoor unit: -40?C to 55?C
Operating Humidity
5% to 95% non-condensing. Outdoor
units are weather protected.
5.11 Standards Compliance, General
EMC
EN 300-385, FCC Part 15
Safety
EN 60950, UL 1950
Environmental
ETS 300 019
Radio
ETSI ETS 300 328, FCC Part 15
