10
Chapter 2. Device setup
Device setup
Installation
What’s Included
• Components may differ in different locations.
• Contact the vendor where you purchased the product if any components are missing.
• The appearance of the components may differ from the images shown.
• A stand is not provided with the product. To install a stand, you can purchase one separately.
• The RS232C adapter can be used to connect to another monitor using the D-SUB (9-pin) type RS232C cable.
+
+
-
-
Quick Setup Guide Warranty card (Not available in
some locations)
Regulatory guide Power cord Batteries (Not available in some
locations)
Remote control RS232C(IN) adapter Screw (M3L8, 1 piece) USB cover
