6
Chapter 1. Safety
Installation
WARNING
Do not place candles, insect repellants or cigarettes on top of the product. Do not
install the product near heat sources.
• A re may result.
Have a technician install the wall-mount hanger.
• Installation by an unqualied person can result in an injury.
• Only use approved cabinets.
Do not install the product in poorly ventilated spaces such as a bookcase or closet.
• An increased internal temperature may cause a re.
Install the product at least 10 cm away from the wall to allow ventilation.
• An increased internal temperature may cause a re.
Keep the plastic packaging out of the reach of children.
• Children may suffocate.
Do not install the product on an unstable or vibrating surface (insecure shelf, sloped
surface, etc.)
• The product may fall and become damaged and/or cause an injury.
• Using the product in an area with excess vibration may damage the product or cause
a re.
Do not install the product in a vehicle or a place exposed to dust, moisture (water
drips, etc.), oil, or smoke.
• A re or electric shock may result.
Do not expose the product to direct sunlight, heat, or a hot object such as a stove.
• The product lifespan may be reduced or a re may result.
Do not install the product within the reach of young children.
• The product may fall and injure children.
• As the front is heavy, install the product on a at and stable surface.
Edible oil, such as soybean oil, can damage or deform the product. Do not install the
product in a kitchen or near a kitchen counter.
CAUTION
Do not drop the product while moving.
• Product failure or personal injury may result.
Do not set down the product on its front.
• The screen may become damaged.
When installing the product on a cabinet or shelf, make sure that the bottom edge of
the front of the product is not protruding.
• The product may fall and become damaged and/or cause an injury.
• Install the product only on cabinets or shelves of the right size.
Set down the product gently.
• Product failure or personal injury may result.
Installing the product in an unusual place (a place exposed to a lot of ne dust,
chemical substances, extreme temperatures or a signicant presence of moisture, or
a place where the product will operate continuously for an extended period of time)
may seriously affect its performance.
• Be sure to consult Samsung Customer Service Centre if you want to install the
product at such a place.
