Tetra Tetronic LED ProLine 980 [13/108] Initial use

Attaching the LED light using screws

The multi adapters are required for this attachment option.

Procedure:

Fig. D

1. Place the multi adapters over the bayonet connectors on the

extension arms.

2. Rotate the multi adapters by 90° until they click into place.

– The multi adapters must be positioned above the lamp.

3. Push the extension arms into the openings at both ends of

the LED light.

– The teeth on the extension arms must point towards the

lamp.

4. Adjust the extension arms to the required length and secure

the multi adapters with three screws each.

– The arms must not be extended by more than 12.5cm

each.

Tetronic LED ProLine Arms

The Tetronic LED ProLine Arms bracket is optionally available for

aquariums or terrariums without a lid.

Procedure:

Fig. F–H

INITIAL USE

The switch on the connection cable enables you to switch the

LED light between day and night mode as well as to switch it o

entirely.

Procedure:

Fig. E

1. Connect the two sections of the connection cable.

2. Plug the power supply into the socket.

– The lowest point of the connection cable must be below

the socket to prevent any water that drips down from

entering the socket.

3. Press the switch.

– 0 = light o

– I = day mode

– II = night mode
