Hardware Installation - 12 -
(Note 1) Due to Windows 32-bit operating system limitation, when more than 4 GB of physical memory is
installed, the actual memory size displayed will be less than 4 GB.
(Note 2) Use of a CPU that supports ECC is required if you wish to install ECC memory.
(Note 3) Whether the CPU/system fan speed control function is supported will depend on the CPU/system
cooler you install.
(Note 4) Available functions in EasyTune may differ by motherboard model.
Hardware Monitor
System voltage detection
CPU/System temperature detection
CPU/system/power fan speed detection
CPU overheating warning
CPU/system/power fan fail warning
CPU/System fan speed control
(Note 3)
BIOS
2 x 8 Mbit ash
Use of licensed AWARD BIOS
Support for DualBIOS
™
PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features
Support for @BIOS
Support for Q-Flash
Support for Xpress BIOS Rescue
Support for Download Center
Support for Xpress Install
Support for Xpress Recovery2
Support for EasyTune
(Note 4)
Support for Easy Energy Saver
Support for Time Repair
Support for Q-Share
Bundled Software
Norton Internet Security (OEM version)
Operating System
Support for Microsoft
®
Windows
®
7/Vista/XP
Form Factor
ATX Form Factor; 30.5cm x 23.0cm
