BIOS Setup - 42 -
Trfc3 for DIMM4
Options are: Auto (default), 90ns, 110ns, 160ns, 300ns, 350ns.
Write Recovery Time
Options are: Auto (default), 5T~8T, 10T, 12T.
Precharge Time
Options are: Auto (default), 4T~7T.
Row Cycle Time
Options are: Auto (default), 11T~42T.
RAS to RAS Delay
Options are: Auto (default), 4T~7T.
Bank Interleaving
Enables or disables memory bank interleaving. Enabled allows the system to simultaneously access dif-
ferent banks of the memory to increase memory performance and stability. (Default: Enabled)
Channel interleave
Enables or disables memory channel interleaving. Enabled allows the system to simultaneously access
different channels of the memory to increase memory performance and stability. (Default: Enabled)
********
System Voltage Optimized
********
System Voltage Control
Determines whether to manually set the system voltages. Auto lets the BIOS automatically set the
system voltages as required. Manual allows all voltage control items below to be congurable. (Default:
Auto)
DRAM Voltage Control
Allows you to set the memory voltage.
Normal Supplies the memory voltage as required. (Default)
1.500V ~ 2.400V The adjustable range is from 1.500V to 2.400V.
Note: Increasing memory voltage may result in damage to the memory or reduce the useful life of the
memory.
DDR VTT Voltage Control
Normal Supplies the memory VTT voltage as required. (Default)
0.900V ~ 1.300V The adjustable range is from 0.900V to 1.300V.
Note: Increasing memory voltage may result in damage to the memory or reduce the useful life of the
memory
NB Voltage Control
Allows you to set the North Bridge voltage.
Normal Supplies the North Bridge voltage as required. (Default)
1.100V ~ 1.800V The adjustable range is from 1.100V to 1.800V.
SB/HT Voltage Control
Allows you to set the South Bridge/HT-Link voltage.
Normal Supplies the South Bridge/HT-Link voltage as required. (Default)
1.200V ~ 1.580V The adjustable range is from 1.200V to 1.580V.
