- 95 - Appendix

For the JMicron JMB362:

Insert the oppy disk containing the SATA RAID/AHCI driver and press <S>. Then a controller menu similar

to Figure 3 below will appear. Select RAID/AHCI Driver for GIGABYTE GBB36X Controller (x32) and press

<Enter>.

Step 3:

On the next screen, press <Enter> to continue the driver installation. After the driver installation, you can pro-

ceed with the Windows XP installation.

Figure 3

Windows Setup

  YouhavechosentocongureaSCSIAdapterforusewithWindows,

using a device support disk provided by an adapter manufacturer.

Select the SCSI Adapter you want from the following list, or press ESC

to return to the previous screen.

ENTER=Select F3=Exit

RAID/AHCI Driver for GIGABYTE GBB36X Controller (x32)

For the Marvell 9128:

Insert the oppy disk containing the SATA AHCI driver and press <S>. The screen will display two drivers,

both of which need to be installed (Figure 4). First select Marvell shared library (install rst) and press

<Enter>. On the next screen, press <S> to return to the screen in Figure 4. Then select Marvell 91xx SATA

Controller 32bit Driver and press <Enter>. When both of the two drivers appear on the conrmation screen,

press <Enter> to continue the driver installation.

Figure 4
