DFL-2100/DFL-2400 Intrusion Detection System User Manual
13
3
3 IDS COMMAND SHELL
DFL-2100/DFL-2400 Console/SSH System
The Console Service on DFL-2100/DFL-2400 provides a text mode interface for
administrators to configure DFL-2100/DFL-2400 via RS-232 serial line. It runs as a shell,
when legal commands are given, it performs the requested tasks.
And, the SSH Service do things like the console service do, actually, they use the same
shell, but there are three points of difference.
i. SSH provides a mechanism that administrator can configure DFL-2100/DFL-2400
remotely via computer network.
ii. Since remote access is considered more risky than accessing from console, some
functions are limited to the console service only. The list of limited functions will
be showed in next section.
iii. For the sake of security, the SSH service can be suspended.
In security field, the common way to protect against brute-force password guess is
increasing the delay time between login attempts. For the console service, it is not
necessary. But for the SSH service, it is necessary. Thus, the SSH login attempt is confined
to 3 times and 60 seconds. If the login failed over 3 times or the user hang on login
procedure over 60 seconds, the SSH connection is cut-off and the resource is released.
Starting DFL-2100/DFL-2400 Command Shell
Once you have accessed the Command Shell with SSH or a Terminal connection, press any
key and the following prompt will appear:
Login as: admin
IDS admin@192.168.168.201’s Password:
D-Link IDS -- Protect your network and servers!
Please enter the login ID（Login：）and password（Password:）
(default login ID：admin；password：DLink)
Login successful user can see the prompt （user can key help or ? to get the setting
information）
>>help
help - This message.
get - Get system information.
set - Set system parameters.
ping - Ping utility
arp - Show & handle arp table.
netstat - Show system network status.
reset - Reset system configurations to manufacturing defaults.
reboot - Reboot system.
>>
