D-Link DIS-100G-5SW [2/13] Hardware overview

Information in this document is subject to change without notice.

Package Contents

Open the shipping carton of the switch and carefully unpack its contents. The carton

should contain the following items:

 DIS-100G-5SW switch

 DC power terminal block

 Wall mounting kit

 DIN-Rail mounting kit

 Quick Installation Guide

Hardware Overview

Interfaces

Interface Description

Ports 1-4 1000Base-T ports

Port 5 1000Base-X SFP port

Table 1

LED Indicators

LED Status Description

ALM On red Power failure alarm occurs.

Off No power failure alarm.

P1 On green P1 power line has power.

Off P1 power line is disconnected or does not have power supply.

P2 On green P2 power line has power.

Off P2 power line is disconnected or does not have power supply.

Link/Act

(Ports 1-4)

On green Ethernet link is up.

Blinking green Ethernet link is up and there is traffic detected.

Off Ethernet link is down.

Speed

(Ports 1-4)

On yellow 1000 Mbps connection is detected.

Off No link or 10/100 Mbps connection is detected.

Link/Act

(Port 5)

On green Ethernet link is up.

Off Ethernet link is down.

1000 (Port 5) On yellow SFP port 1000 Mbps connection is detected.
