![D-Link DGS-1100-10MP [31/103] Ipv6 interface](/views2/1458713/page31/bg1f.png)
D-Link DGS-1100 MP/MPP Series Switch User Manual
25
The fields that can be configured are described below:
Parameter Description
Get IP From
Select DHCP to automatically obtain an IP address. Select
Static to manually configure the IP address settings. BOOTP
allows the switch to get an IP configuration using the BOOTP
protocol.
IP Address
If Static is selected, enter the IP address of the switch. If
DHCP or BOOTP is selected, the automatically obtained IP
address will be displayed.
Mask
If Static is selected, enter the IP address of the switch. If
DHCP or BOOTP is selected, the automatically obtained
network mask will be displayed.
Gateway
If Static is selected, enter the IP address of the switch. If
DHCP or BOOTP is selected, the automatically obtained
gateway will be displayed.
DHCP retry Time
If DHCP is selected, enter the number of times to retry
obtaining an IP address.
Click the Apply button to accept the changes made.
IPv6 Interface
This window is used to configure the IPv6 settings of the switch.
To view the following window, click System > System Information Settings > IPv6 Interface, as
shown below:
Figure 6-3 Peripheral Settings window
The fields that can be configured are described below:
Parameter Description
IPv6 State Select whether to Enable or Disable IPv6 functionality.
Static IPv6 Address
If enabled, enter the static IPv6 address of the switch.
Click the Apply button to accept the changes made.
Port Configuration
Port Settings
This window is used to view and configure the switch’s port settings.
To view the following window, click System > Port Configuration > Port Settings, as shown below:
