D-Link DGS-1100 MP/MPP Series Switch User Manual
3
2. Product Introduction
The DGS-1100 MP/MPP series Smart Switch is the world’s first PoE switch with ONVIF support.
This allows it to recognize ONVIF devices and integrate seamlessly with your surveillance network.
Various power budgets, support for high powered PoE standards (MPP series) and 6 KV surge
protection make the DGS-1100 MP/MPP series a critical part of your surveillance infrastructure.
The DGS-1100 MP/MPP series switches can change modes between ‘Smart Switch’ and
‘Surveillance Switch’ modes, making them suitable for a variety of applications. An intuitive web user
interface makes advanced features available in the Standard Mode, with full PoE capabilities and
high link speeds improving deployment times for PoE devices.
The switches are designed to be energy efficient with support for IEEE 802.3az Energy Efficient
Ethernet (EEE) and D-Link Green Technologies. They include multiple features, such as cable
length detection, port status detection and the ability to hibernate under low utilization. If the switch
detects no activity on any of the switch ports, it can be hibernated to conserve power.
The DGS-1100 MPP series provides multiple PoE ports that support IEEE 802.3bt, allowing the
latest high-powered PoE devices to be used with the switch. Automatic device identification, video
traffic optimization and health diagnostic tools provide an intelligent solution to your enterprise
network requirements.
