D-Link DGS-1510-10L/ME [270/342] Dns resolver static name server settings

DGS-1510/ME Series Metro Ethernet Switch Web UI Reference Guide

261

Parameter Description

DNS Resolver State

Click the radio buttons to enable or disable the DNS resolver state.

Name Server Timeout (1-

60)

The maximum time waiting for a response from a specified name server.

Click the Apply button to accept the changes made.

DNS Resolver Static Name Server Settings

The window is used to create the DNS Resolver name server of the switch. When adding a name server, if one

primary name server exists in the static name server table and a new primary name server is added, the existing

primary name server will be changed to a normal name server. If the added primary name server’s IP address is the

same as an existing normal name server’s IP address, the existing normal name server will be changed to a primary

name server, but won’t add new name server. When no primary name server is specified, the first configured name

server will automatically change to become the primary name server. If the deleted name server’s IP address is the

same as one of the existing name servers’ IP addresses, regardless of whether a normal name server or primary

name server, the name server will be deleted.

To view this window, click Network Application > DNS Resolver > DNS Resolver Static Name Server Settings as

shown below:

Figure 9-12 DNS Resolver Static Name Server Settings window

The fields that can be configured are described below:

Parameter Description

Server IP Address

Enter a DNS Resolver name server’s IPv4 address here.

Server IPv6 Address

Enter a DNS Resolver name server’s IPv6 address here.

Primary

Select to set the name server as a primary name server.

Click the Add button to add a new entry based on the information entered.

Click the Delete button to remove the specific entry.

DNS Resolver Dynamic Name Server Table

This window displays the current DNS Resolver name servers.

To view this window, click Network Application > DNS Resolver > DNS Resolver Dynamic Name Server Table as

shown below:

Figure 9-13 DNS Resolver Dynamic Name Server Table window

DNS Resolver Static Host Name Settings

The window is used to create the static host name entry of the switch.
