D-Link DGS-1510-10L/ME [319/342] Upload firmware to ftp

DGS-1510/ME Series Metro Ethernet Switch Web UI Reference Guide

310

Domain Name

Click the radio button to enter the TFTP server domain name used.

Destination File

Enter the file name that will be stored in the TFTP server, e.g. runtime.had.

Source File

Enter the location of the Source File, e.g. C:/runtime.had.

Click Upload to initiate the upload.

Upload Firmware To FTP

This window is used to upload firmware from the Switch to a FTP Server.

Figure 12-8 Upload Firmware – FTP window

The fields that can be configured are described below:

Parameter Description

FTP Server IP

Enter the FTP Server IP Address used.

User Name

Enter the appropriate Username used.

Password

Enter the appropriate Password used.

TCP Port (1-65535)

Enter the TCP Port number used.

Destination File

Enter the file name that will be stored in the FTP server, e.g. runtime.had.

Source File

Enter the location of the Source File, e.g. C:/runtime.had.

Click Upload to initiate the upload.

Upload Firmware To HTTP

This window is used to upload firmware from the Switch to a computer.

Figure 12-9 Upload Firmware – HTTP window

The fields that can be configured are described below:

Parameter Description

Source File

Enter the location and name of the Source File.

Click Upload to initiate the upload.
