The fields that can be configured are described below:
Parameter Description
Confederation Identifier
(0-4294967295)
Enter an Autonomous System number which is used to specify a BGP
confederation. If it is set to zero, the BGP confederation number is deleted. By
default, this setting is zero.
Confederation Peer
Action
Use the drop-down menu to select Add or Delete.
Confederation Peer AS
List (1-4294967295)
Enter one or multiple AS number partitions, each separated by a comma. These are
the Autonomous System numbers for BGP peers that will belong to the
confederation.
Click the Apply button to accept the changes made.
BGP AS Path Access Settings
This window is used to configure an Autonomous System path access list.
To view the following window, click L3 Features > BGP > BGP AS Path Access Settings, as shown below:
Figure 6-162 BGP AS Path Access Settings window
The fields that can be configured are described below:
Parameter Description
List Name
Enter an Autonomous System path access list name.
Click the Add button to add a new entry based on the information entered.
Click the Find button to locate a specific entry based on the information entered.
Click the Delete All button to remove all the entries listed.
Click the View All button to display all the existing entries.
Click the View Detail link to view more information regarding the specific entry.
Click the Delete button to remove the specific entry.
Click the View Detail link to see the following window.
