Common Settings
Current
Configuration
Version
Show the current config file’s version. If the version of configuration
downloaded is higher than this, the configuration will be upgraded. If the
endpoints confirm the configuration by the Digest method, the configuration
will not be upgraded unless it differs from the current configuration
General
Configuration
Version
Show the common config file’s version. If the configuration downloaded and
this configuration is the same, the auto provision will stop. If the endpoints
confirm the configuration by the Digest method, the configuration will not be
upgraded unless it differs from the current configuration.
CPE Serial Number Serial number of the equipment
Authentication
Name
Username for configuration server. Used for FTP/HTTP/HTTPS. If this is
blank the phone will use anonymous
Authentication
Password
Password for configuration server. Used for FTP/HTTP/HTTPS.
Configuration File
Encryption Key
Encryption key for the configuration file
General
Configuration File
Encryption Key
Encryption key for common configuration file
DHCP Option
Option Value
The equipment supports configuration from Option 43, Option 66, or a Custom
DHCP option. It may also be disabled.
Custom Option
Value
Custom option number. Must be from 128 to 254.
SIP Plug and Play (PnP)
Enable SIP PnP
If this is enabled, the equipment will send SIP SUBSCRIBE messages to a
multicast address when it boots up. Any SIP server understanding that message
will reply with a SIP NOTIFY message containing the Auto Provisioning
Server URL where the phones can request their configuration.
Server Address PnP Server Address
Server Port PnP Server Port
Transportation
Protocol
PnP Transfer protocol – UDP or TCP
Update Interval Interval time for querying PnP server. Default is 1 hour.
Static Provisioning Server
Server Address Set FTP/TFTP/HTTP server IP address for auto update. The address can be an
21
