IP address or Domain name with subdirectory.
Configuration File
Name
Specify configuration file name. The equipment will use its MAC ID as the
config file name if this is blank.
Protocol Type Specify the Protocol type FTP, TFTP or HTTP.
Update Interval Specify the update interval time. Default is 1 hour.
Update Mode
1. Disable – no update
2. Update after reboot – update only after reboot.
3. Update at time interval – update at periodic update interval
TR069
Enable TR069 Enable/Disable TR069 configuration
ACS Server Type Select Common or CTC ACS Server Type.
ACS Server URL ACS Server URL.
ACS User User name for ACS.
ACS Password ACS Password.
TR069 Auto Login Enable/Disable TR069 Auto Login.
INFORM Sending
Period
Time between transmissions of “Inform” Unit is seconds.
5.3.1.6 Tools
Syslog is a protocol used to record log messages using a client/server mechanism. The
Syslog server receives the messages from clients, and classifies them based on priority and
type. Then these messages will be written into a log by rules which the administrator has
configured.
There are 8 levels of debug information.
Level 0: emergency; System is unusable. This is the highest debug info level.
22
