Advanced
Field Name Explanation
Link Layer Discovery Protocol (LLDP) Settings
Enable LLDP Enable or Disable Link Layer Discovery Protocol (LLDP)
Enable Learning
Function
Enables the telephone to synchronize its VLAN data with the Network
Switch. The telephone will automatically synchronize DSCP, 802.1p, and
VLAN ID values even if these values differ from those provided by the
LLDP server.
Packet Interval(1~3600) The time interval for sending LLDP Packets
VLAN Settings
Enable VLAN Enable or Disable WAN Port VLAN
VLAN ID Specify the value of the VLAN ID. Range is 0-4095
802.1p Signal Priority Specify the value of the signal 802.1p priority. Range is 0-7
802.1p Media Priority Specify the value of the voice 802.1p priority. Range is 0-7
Quality of Service (QoS) Settings
Enable DSCP QoS Enable or Disable Differentiated Services Code Point (DSCP)
Media QoS Priority Specify the value of the Media DSCP in decimal
Signal QoS Priority Specify the value of the Signal DSCP in decimal
26
