D-Link DPH-200SE [20/53] Network

Field Name Explanation

Network Status

IP The current IP address of the equipment

Subnet mask The current Subnet Mask

Default gateway The current Gateway IP address

MAC The MAC address of the equipment

MAC Timestamp Get the MAC address of time.

Settings

Select the appropriate network mode. The equipment supports three network modes:

Static IP

Network parameters must be entered manually and will not change. All

parameters are provided by the ISP.

DHCP Network parameters are provided automatically by a DHCP server.

PPPoE Account and Password must be input manually. These are provided by your ISP.

If Static IP is chosen, the screen below will appear. Enter values provided by the ISP.

DNS Server

Configured by

Select the Configured mode of the DNS Server.

Primary DNS

Server

Enter the server address of the Primary DNS.

Secondary DNS

Server

Enter the server address of the Secondary DNS.

After entering the new settings, click the APPLY button. The equipment will save the new settings

and apply them. If a new IP address was entered for the equipment, it must be used to login to the

phone after clicking the APPLY button.

5.3.2.2 Advanced

The equipment supports 802.1Q/P protocol and DiffServ configuration. VLAN function can

support the different VLAN ID mode of processing in the WAN port and LAN port.

 Chart 1 shows a network switch with no VLAN. Any broadcast frames will be transmitted to

all other ports. For example, frames broadcast from Port 1 will be sent to Ports 2, 3, and 4.
