2.2 Operating Conditions

This device is for indoor use only!

The sterilizer should be loaded only with autoclavable material!

The environment shall not exceed an ambient temperature of 104ºF

(40ºC) and a relative humidity of 85% respectively.

For optimal results from the first sterilization cycle, it is recommended to

perform a B & D cycle (cycle # 5) at the beginning of each working day.

2.3 Stand – by heating mode

While the autoclave is in the jacket heating stage, “St.By” is displayed in

the upper right corner of the LCD screen. This announcement is

maintained until the jacket reaches its working pressure, at which time

the message will change to “READY”. When the unit is first turned on it

will take approximately 10 - 20 minutes for the jacket to reach its

working pressure and temperature.

2.4 Utilities

For proper operation, these are the required utilities that need to be

supplied:

Site requirements for installation of a 2540 EHS

1. Counter top able to support a minimum 200 lb. * (the unit is shipped

with a suitable stand - 26”W x 33”D x 34”H)

2. Counter space minimum 20”W x 32”D x 20”H * (see unit dimensions

below)

3. City water supply 15 – 58 psi with shut off valve having ½” NPT male

end. Higher rates of pressure will require the installation of a pressure

reducer (58 psi max) The minimum flow rate required is 0.66 gal/min.

(2.5 lit./min.). Installation of the valve should be 2” above counter height

at the rear of the unit.

4. Mineral Free water supply 7 – 30 psi with shut off valve and ½” NPT

male end. If the water pressure, at the autoclave inlet, is higher then 58

psi (4 bar), adjust the shut off valve for a low water flow into the mineral

free water reservoir. The minimum rate of flow is 0.26 gal/min (1

lit/min). Installation of the valve should be 2” above counter height at the

rear of the unit. * (an optional R.O. water system is available).

5. Electrical power 20A – 208V single phase. Connection required; flush

mount receptacle 6-20R, within 1 foot of the rear of the unit.

6. Drainage should be to a 4” high 4” diameter air break, reducing down to

a 1 ½” vented line with a trap. All drainage components must be able to

withstand a non-continuous temperature of 140°F (60°C). Drain opening

should be within 1 foot of the rear of the unit and no higher than 16”

above the floor. The use of two ½”x 6" Milford Type Copper Coated

Hangers is required for the positioning of the two drain hoses over the

center of the air break and a 4” metal worm gear clamp to secure the

hangers. The hangers will need to be bent at a 90º angle to allow for

proper positioning and securing with the clamp. * (see attached drawing)
