Tp-Link Archer MR400 V1 [48/92] Chapter 11

Chapter 11

Specify Your Network

Settings

This chapter introduces how to change the default settings or adjust the basic

configuration of the router using the web-based management page.

This chapter contains the following sections:

• FAQUSSD

• PIN Management

• Data Settings

• LAN Settings

• Wireless Settings

• Set Up a Dynamic DNS Service Account

• Create Static Routes

• Set up a VPN Connection
