Tp-Link Archer MR400 V1 [68/92] Chapter 12

Chapter 12

Administrate Your Network

This chapter introduces how to change the system settings and administrate your

router’s network.

This chapter contains the following sections:

• Set System Time

• Update the Firmware

• Back up and Restore Configuration Settings

• Change the Administrator Account

• Local Management

• Remote Management

• System Log

• Monitor the Internet Traffic Statistics

• CWMP Settings

• SNMP Settings
