TX-6610 1-Port Gigabit GPON Terminal User Guide

Appendix B: Troubleshooting

T1. How to connect to the Internet?

To connect to the Internet, please run the dialing software such as WinPoet or EnterNet to do the

virtual dialing as the following described.

For Mac OS X

• Click the Apple icon on the upper left corner of the screen.

• Go to “System Preferences -> Internet & Wireless -> Network” and then select Ethernet.

• In the Con-figure IPv4 box, select Create PPPoE Service.

• Type a Service Name to identify your connection.

• Enter the User name and Password given by your ISP and then click Apply and Connect.

For Windows 7

• Click Start -> Control Panel.

• Click Network and Sharing Center.

• Click Set up a new connection or network.

• Click Connect to the Internet and then click Next.

• Click Broadband (PPPoE).

• Enter the User name and Password given by your ISP, and type a Connection name to

identify your connection, and then click Connect.

For Windows XP

• Click “Start Æ All Programs Æ Accessories Æ Communications Æ New connection

wizard” to launch the wizard. Then click Next.

• Select Connect to the Internet and then click Next.

• Select Set up my connection manually and then click Next.

• Select Connect using a broadband connection that requires user name and password

and then click Next.

• Type an ISP Name to identify your connection and then click Next.

• Enter the User name and Password given by your ISP and then click Next.

• Select Add a shortcut to this connection to my desktop for convenience and then click

Finish.

• The shortcut icon

of this connection will appear on your desktop. Double-click the icon

to run the dialing software and then click Connect.

For Windows 8

• Move your mouse to the lower right corner and you will see the Search icon in the Popups.

• Go to Apps, type Control Panel in the search box and press Enter.

• Go to “Control Panel -> Network and Internet -> Connect to the Internet”.
