LAUNCH CR-HD User's Manual
4
③
ENTER BUTTON Conrms a selection (or action) from a menu
list.
④/⑥
UP/DOWN BUTTONs Move cursor up or down for selection.
⑤/⑦
RIGHT/LEFT BUTTONs Move cursor right or left for selection; Or
turn page up or down when more than one
page is displayed.
⑧
USB PORT Connects to computer to update the CR-HD
online.
⑨
EXIT BUTTON Returns to previous menu.
A RED LED INDICATOR
LAMP
DTC indicator; once DTCs are found, the
red indicator lamp will light up.
B GREEN LED
INDICATOR LAMP
No DTC indicator; when there are no DTCs,
the green indicator lamp will light up.
C 6 PIN DLC ADAPTOR
(For vehicles with 6
PIN DLC)
Connect 16 pin terminal of the adaptor to
OBD II connector, and other end to the
vehicle’s DLC.
D 9 PIN DLC ADAPTOR
(For vehicles with 9
PIN DLC)
Connect 16 pin terminal of the adaptor to
OBD II connector, and other end to the
vehicle’s DLC.
3.2 Specications
Screen: 2.8” TFT 262K true color, 320*240 QVGA LCD display•
Input voltage range: 8~32V•
Operating current: <100mA@12V (Typical)•
Power consumption: <1.2W (Typical)•
Operating temperature: 32°F~122°F / 0°C~50°C•
Storage tempetature: -4°F~158°F / -20°C ~70°C @ RH60%•
Outline dimension: 4.7’*3.2’*1.0’ / 121*82*26 mm LWH•
Weight : <17.6 oz (500g)•
3.3 Accessories Included
User’s Manual -- Instructions on tool operations1.
6 PIN DLC adaptor 2.
9 PIN DLC adaptor3.
USB cable -- Connect to a computer for upgrading online 4.
