English 5 Change rotation speed Regarding electric discharge In case of new batteries etc Operate the shift knob to change the rotational speed Move the shift knob in the direction of the arrow see As the internal chemical substances of new batteries and batteries that have not been used for an extended period is not activated the electric discharge might be low when using them for the first and second times This is a temporary phenomenon and normal time required for recharging will be restored by recharging the batteries 2 3 times How to make the batteries perform longer 1 Recharge the batteries before they become completely exhausted When you feel that the power of the tool becomes weaker stop using the tool and recharge its battery If you continue to use the tool and exhaust the electric current the battery may be damaged and its life will become shorter 2 Avoid recharging at high temperatures A rechargeable battery will be hot immediately after use If such a battery is recharged immediately after use its internal chemical substance will deteriorate and the battery life will be shortened Leavethe battery for a while and recharge it after it has cooled CAUTION O When the battery charger has been continuously used the battery charger will be heated thus constituting the cause of failures Once the charging has been completed give 15 minutes rest until the next charging O If the battery charger does not work while the battery is mounted correctly it is probable that the battery or charger is malfunctioning Take it to your authorized Service Center PRIOR TO OPERATION 1 Setting up and checking the work environment Check if the work environment is suitable by following the precautions HOW TO USE How to make the batteries perform longer O Recharge the batteries before they become completely exhausted When you feel that the power of the tool becomes weaker stop using the tool and recharge its battery If you continue to use the tool and exhaust the electric current the battery may be damaged and its life will become shorter 1 Installing the bit Always follow the following procedure to install driver bit Fig 4 1 Pull the guide sleeve forward 2 Insert the bit into the hexagonal hole in the socket 3 Release the guide sleeve and it returns to its original position CAUTION If the guide sleeve does not return position then the bit is not installed properly to its original 2 Removing the bit Please do installing bit the opposite point on the method of 3 Automatic spindle lock mechanism When the main switch is off the bit is locked in place and the tool can be used as a manual screwdriver 4 Confirm that the battery Is mounted correctly 10 Figs 5 and 6 When the shift knob is set to LOW the drill rotates at a low speed When set to HIGH the drill rotates at a high speed CAUTION O When changing the rotational knob confirm that the switch is off Changing the speed while the damage the gears O When a large force is required shift knob to LOW If HIGH used it may cause the motor to prematurely speed with motor is the rotating shift will for operation set the is set and the unit is burn out or malfunction 6 Confirm the clutch dial position See Fig 7 The tightening torque of this unit can be adjusted according tothe clutch dial position at which the clutch dial is set 1 When using this unit as a screwdriver line up the one of the numbers 1 5 9 21 on the clutch dial or the black dots with the triangle mark on the outer body 2 When using this unit as a drill align the clutch dial drill markwith the triangle mark on the outer body CAUTION O The clutch dial cannot be set between the numerals 1 5 9 21 or the black dots O Do not use with the clutch dial numeral between 22 and the black line at the middle of the drill mark Doing so may cause damage See Fig 8 7 Tightening torque adjustment 1 Tightening torque Tightening torque should correspond in its intensity to the screw diameter When too strong torque is used the screw head may be broken or be injured Be sure to adjust the clutch dial position according tothe screw diameter 2 Tightening torque indication See Fig 7 The tightening torque differs depending on the type of screw and the material being tightened The unit indicates the tightening torque with the numbers 1 5 9 21 and black dots on the clutch dial The tightening toque at position 1 is the weakest and the torque is strongest at the highest number 3 Adjusting the tightening torque See Fig 7 Rotate the clutch dial and line up the numbers 1 5 9 21 or the dots on the clutch dial with the triangle mark on the outer body Adjust the clutch dial in the weak or the strong torque direction according to the torque you need CAUTION O The motor rotation may be looked to cease while the unit is used as drill While operating the driver drill take care not to lock the motor O When setting the shift knob to HIGH high speed and the position of the clutch dial is 10 or 22 it may happen that the clutch does not engaged and that the motor is locked In such a case please set the shift knob to LOW lowspeed O If the motor is locked immediately turn the power off If the motor is looked for a while the motor or battery may be burnt O Too long hammering may cause the screw broken due to excessive tightening 8 Switch operation 1 Lock switch The tool is equipped with a lock switch To activate the main switch lock move the lock switch to the LOCK position Move the lock switch to the opposite position to operate thetool Fig 9
