Hikoki DB 3DL2 [11/60] English



English













































































 























 









 

 

 





ー

，

、







 

，

ヽ



























































『

























Содержание

Похожие устройства

English 10 Using In the straight or pistol configuration CAUTION Always set the lock switch to the LOCK position when carrying or storing the tool eliminate unintentional starting 2 Main switch The main switch functions as a motor switch and rotational direction selector switch When the main switch is pushed to R indicated on the main switch the bit rotates clockwise When the main switch is pushed to L indicated on the main switch the bit rotates counterclockwise When the main switch is released the tool stops Fig 10 Use the tool in the straight configuration when using in confined spaces Use it in the pistol configuration when using in other locations Select the configuration that best matches the tool application When changing the configuration the tool will make a clicking sound when it snaps into position Bend or extend the tool until the clicking sound is heard CAUTION When using the tool in the pistol configuration do not hold onto the bending portion of the tool when returning to the straight configuration Your finger or other part of the hand may be pinched by the bending portion resulting in possible injury Fig 12 9 Using the light The light lights when the light switch is pushed When the light switch is pushed again the light is turned off 11 The scope and suggestions for uses Fig 11 CAUTION The usable scope for various types of work based on the mechanical structure of this unit is shown in Table 2 Do not look directly into the light Such actions could result in eyein ury Table 2 Work Drilling Suggestions Steel Use fordrilling purpose Aluminum Driving Machine screw Use the bit or socket matching the screw diameter Wood screw Use after drilling a pilot hole 12 Howto select tightening torque and rotational speed Table 3 Rotating speed selection Position of the shift knob Use Machine screw Wood screw Drilling Metal HIGH High speed LOW Low speed 1 21 Я Driving Cap Position For 5 mm or smaller diameter screws For 3 mm or smaller diameter screws For 3 5 mm or smaller nominal diameter screws For drilling with a metal working drill bit CAUTION O The selection examples shown in Table 3 should be considered as general standard As different types of tightening screws and different materials to be tightened are used in actual works proper adjustments are naturally necessary O When using the driver drill with a machine screw at HIGH high speed a screw may damage or a bit may loosen due to the tightening torque too strong Use the driver drill at LOW low speed when using a machine screw NOTE The use of the battery EBM315 in a cold condition below 0 degree Centigrade can sometimes result in the weakened tightening torque and reduced amount of work This however is a temporary phenomenon and returns to normal when the battery warms up MAINTENANCE AND INSPECTION 1 Inspecting the tool Since use of as dull tool will degrade efficiency and cause possible motor malfunction sharpen or replace the tool as soon as abrasion is noted 2 Inspecting the mounting screws Regularly inspect all mounting screws and ensure that they are properly tightened Should any of the screws be loose retighten them immediately Failure to do so could result in serious hazard 3 Maintenance of the motor The motor unit winding is the very heart of the power tool Exercise due care to ensure the winding does not become damaged and or wet with oil orwater 4 Cleaning on the outside When the driver drill is stained wipe with a soft dry cloth or a cloth moistened with soapy water Do not use chloric solvents gasoline or paint thinner for they melt plastics 11
