6
English
SPECIFICATIONS
Model D10VF D10VG D13VF D13VG
Voltage (by areas)* (110V, 220V, 230V, 240V)
Power input 710W*
No load speed 0–3,000min
–1
0–1,200min
–1
0–850min
–1
0–600min
–1
Drill chuck capacity 10 mm 13 mm
Steel
Twist Bit 10 mm 10 mm 13 mm 13 mm
Hole Saw – 38 mm 51 mm 70 mm
Capacity Flat Spade Bit 25 mm 32 mm 40 mm 40 mm
Wood Auger Bit – – 32 mm 38 mm
Hole Saw 29 mm 70 mm 102 mm 114 mm
Weight (without cord)
Spec. for keyed chuck 1.8 kg 1.9 kg 2.1 kg 2.1 kg
Spec. for keyless chuck 1.8 kg 1.9 kg 2.0 kg 2.0 kg
*Be sure to check the nameplate on product as it is subject to change by areas.
<Capacity with Angle attachment (Optional accessory for D13VF and D13VG)>
Model D13VF D13VG
Speed of angle unit LOW(650min
–1
)HIGH(1350min
–1
) LOW(400min
–1
) HIGH(900min
–1
)
Steel
Twist Bit 13 mm 13 mm 13 mm 13 mm
Hole Saw 64 mm 32 mm 70 mm 51 mm
Capacity Flat Spade Bit 40 mm 32 mm 40 mm 40 mm
Wood Auger Bit 38 mm 29 mm 38 mm 32 mm
Hole Saw 114 mm 64 mm 114 mm 102 mm
STANDARD ACCESSORIES
<D10VF>
(1) Chuck wrench (Spec. only for keyed chuck) ...... 1
<D10VG and D13VF>
(1) Side handle ................................................................ 1
(2)Chuck wrench (Spec. only for keyed chuck) ........ 1
<D13VG>
(1) Side handle ................................................................ 1
(2) Handle joint ................................................................ 1
(3) Chuck wrench (Spec. only for keyed chuck) ...... 1
Standard accessories are subject to change without notice.
OPTIONAL ACCESSORIES (sold separately)
<D10VF>
(1) Side handle
(2) Hook (A)
<D10VG>
(1) Hook (A)
<D13VF and D13VG>
(1) Hook (A)
(2) Angle attachment
Optional accessories are subject to change without notice.
APPLICATIONS
䡬 Boring holes in metal, wood and plastic.
PRIOR TO OPERATION
1. Power source
Ensure that the power source to be utilized conforms
to the power requirements specified on the product
nameplate.
2. Power switch
Ensure that the power switch is in the OFF position.
If the plug is connected to a receptacle while the
power switch is in the ON position, the power tool
will start operating immediately, inviting serious
accident.
DRILL SAFETY WARNINGS
1. Wear ear protectors with impact drills.
Exposure to noise can cause hearing loss.
2. Use auxiliary handles supplied with the tool.
Loss of control can cause personal injury.
3. Hold the drill and side handle securely with both
hands when using.
4. Do not wear gloves made of stuff liable to roll up
such as cotton, wool, cloth or string, etc.
5. Prior to drilling into walls, ceilings or floors, ensure
there are no electric cables or conduits inside.
01Eng_D10VF_WE 3/2/09, 20:246
