CPS1500PIE
Copyright © 2014 CyberPower Systems, Inc.
11
Step 3: Press and hold the toggle for 4 seconds. When the icons blink, the value of each item can be
changed by slightly pressing the toggle.
Step 4: To save the value and return to general mode, press and hold the toggle for 4 seconds.
Note: If the machine is left idle for over 30 seconds during setup, it will turn off the backlight
and return to general mode automatically.
Note: If user wants to return to general mode without saving changes, there are two methods:
1. Wait for the backlight to turn off
2. Press and hold the Display Toggle for 10 seconds
BATTERY CHARGING SETTING ARRANGEMENT
Please read the following instructions and cautions carefully before charging the battery.
Step 1: Press the LCD Display Toggle (Selected Switch) on the front panel for 10 seconds and let the
EPS enter Set-up Mode.
Step 2: By pressing the Display Toggle, switch setup function to Battery Capacity / Charging Current.
Step 3: Press and hold the toggle for 4 seconds. When the icons blink, slightly press the toggle to
choose the value of the battery capacity / charging current. Please refer to the following table
for suitable setting.
LOWEST
LOW
MEDIUM (default)
HIGH
current
time*
current
time
current
time
current
time
50 AH
3A
30hr
6A
11hr
8A
9hr
75 AH
4A
30hr
10A
11hr
13A
9hr
100 AH
5A
30hr
10A
15hr
14A
11hr
17A
9hr
Others (0H)**
5A (default), 10A, 15A, 20A
* Time here indicates charging hours needed for the battery.
** Due to the fact that the inappropriate charging current will seriously cause the decrease of the lifespan of the battery,
please DO NOT use the 0H setting without the assistance from local agent. Improper use is not incorporated in the
warranty.
Step 4: Press and hold the toggle for 4 seconds to save the setting value and return to general mode.
