Tp-Link T1700X-16TS V1 [5/28] Contents

III

Contents

Chapter 1 Introduction ———————————— 01

1.1

Product Overview .....................................01

1.2 Appearance

................................................... 0

Chapter 2 Installation ———————————— 04

2.1 Package Contents .....................................04

2.2 Safety Precautions ....................................04

2.3 Installation Tools ......................................06

2.4 Product Installation ..................................07

Chapter 3 Lightning Protection ———————— 09

3.1 Cabling Reasonably ..................................09

3.2 Connect to Ground ...................................11

3.3 Equipotential Bonding ............................... 12

3.4 Use Lightning Arrester ..............................13

Chapter 4 Connection ———————————— 15

4.1 Ethernet Port ...........................................15

4.2 SFP Port ..................................................15

4.3 Verify Installation .....................................15

4.4 Power On ................................................16

4.5 Initialization .............................................16

Chapter 5 Conguration ——————————— 17

5.1 Congure the Switch via GUI ....................17

5.2 Congure the Switch Using CLI .................18

Appendix A Troubleshooting —————————— 20

Appendix B Hardware Specications —————— 21
