- 51 - BIOS Setup
English
Current CPU Temperature
Detect CPU Temp. automatically..
Current CPU/SYSTEM FAN Speed (RPM)
Detect CPU/SYSTEM Fan speed status automatically.
CPU Warning Temperature
60
o
C / 140
o
F Monitor CPU Temp. at 60
o
C / 140
o
F.
70
o
C / 158
o
F Monitor CPU Temp. at 70
o
C / 158
o
F.
80
o
C / 176
o
F Monitor CPU Temp. at 80
o
C / 176
o
F.
90
o
C / 194
o
F Monitor CPU Temp. at 90
o
C / 194
o
F.
8Disabled Disable this function.(Default v alue)
CPU FAN Fail Warning
Disabled Fan Warning Function Disable. (Default value)
Enabled Fan Warning Function Enable.
SYSTEM FAN Fail Warning
Disabled Fan Warning Function Disable. (Default value)
Enabled Fan Warning Function Enable.
8ig1000mt_1001_b.p65 2003/4/15, 下午 03:1151
