Gigabyte GA-8IG1000MT [85/96] Easytune 4 utilities installation
![Gigabyte GA-8IG1000MT [85/96] Easytune 4 utilities installation](/views2/1047280/page85/bg55.png)
Appendix- 81 -
English
EasyTune 4 Utilities Installation
Powerful utility that integrates the overclocking and hardware monitoring functions
(1)
(2)
(4)
1. Click "EasyTune4" item.
2. Click "Next".
(3)
(6)
(5)
3. Click "Finish" to restart computer.
4. Right Click the icon to start
"EasyTune 4".
8ig1000mt_1001_a.p65 2003/4/15, 下午 03:1381
