The following entries are displayed on this screen:

 Storm Control Setting

Port:

Select the desired port for storm c

ontrol configuration. It is

multi-optional.

Status:

Allows you to enable or disable the storm control function.

Total Rate(Kbit/sec):

Select the rate

for receiving packets on the port. The packet

traffic exceeding the rate will be discarded. It

ranges from 0 to

100000, and must be integral multiple of 64.

Included Storm

Type:

Select to filter broadcast/multicast/UL frame in the network, i

f the

transmission rate of the chosen packets exceeds the set rate

, the

packets will be automatically discard

ed to avoid network

broadcast storm. It is multi-optional.

• UL-Frame: If UL-Frame packets traffic exceeds the rate

the port, they will be discarded.

• Multicast: If multicast packets traffic exceeds the rate

on the

port, they will be discarded.

• Broadcast: If broadcast packets traffic exceeds the rate

the port, they will be discarded.

Note:

If you enable storm control feature for the ingress rate control-enabled port, the ingress rate

control feature will be disabled for this port.
