- 56 -GA-8ILML4 Motherboard
English
A-2. Intel Application Accelerator
(2)
(3)
(5)
(6)
Insert the driver CD-title that came with your motherboard into your CD-ROM driver, the driver
CD-title will auto start and show the installation guide. If not, please double click the CD-ROM device
icon in "My computer", and execute the setup.exe.
(1)
2.Click "Next".
4.Click "Next".
5.Click "Next".
1.Click "Intel Application Accelerator" item.
(4)
3.Click "Yes".
