Introduction
English
- 5 -
Form Factor — 21.0cm x 24.3cm Micro ATX size form factor, 4 layers PCB.
CPU — Socket 478 for Intel
®
Micro FC-PGA2 Pentium
®
4 processor
— Support Intel
®
Pentium
®
4 (Northwood, 0.13 m) processor
— Intel Pentium
®
4 400MHz FSB
— 2nd cache depends on CPU
Chipset — Chipset 82845GL HOST/AGP/Controller
— ICH4 I/O Controller Hub
Memory — 2 184-pin DDR DIMM sockets
— Supports PC1600 DDR or PC2100 DDR SDRAM
— Supports up to 2GB DRAM (Max)
— Supports only 2.5V DDR SDRAM
I/O Control — ITE8712
Slots — 3 PCI slot supports 33MHz & PCI 2.2 compliant
On-Board IDE — 2 IDE controller on the Intel ICH4 PCI chipset
provides IDE HDD/CD-ROM with PIO, Bus Master (Ultra
DMA33/ATA66/ATA100) operation modes.
— Can connect up to four IDE devices
On-Board Peripherals — 1 Floppy port supports 2 FDD with 360K, 720K,1.2M, 1.44M
and 2.88M bytes.
— 1 Parallel port supports Normal/EPP/ECP mode
— 1 Serial ports (COMA), 1 VGA port
— 1 COMB onboard
— 6 x USB 2.0/1.1 (2x Rear, 4 by optional cable)
— 1 IrDA connector for IR
— 1 Front Audio connector
On-Board VGA — Built in Intel 845GL Chipset
On-Board Sound — Sigmatel 9721 CODEC
— 1 Buzzer
— Line In/Line Out/Mic In/CD In/AUX In/Game Port
On-Board LAN — Builit in Intel 82562ET Chipset
— 1 RJ 45 port
