- 60 -GA-8ILML4 Motherboard
English
Revision History
Insert the driver CD-title that came with your motherboard into your CD-ROM driver, the driver
CD-title will auto start and show the installation guide. If not, please double click the CD-ROM device
icon in "My computer", and execute the setup.exe.
Revision History
Appendix B: Sigmatel AC’97 Audio Driver
(1)
1.Click "Sigmatel AC’97 Audio Driver"
item.
(2)
(3)
3.Click "Finish" to restart computer.
(4)
2.Click "Next".
