- 4 -GA-8GE800 Pro Motherboard
English
Item Checklist
Computer motherboards and expansion cards contain very delicate Integrated Circuit (IC) chips. To
protect them against damage from static electricity, you should follow some precautions whenever you
work on your computer.
1. Unplug your computer when working on the inside.
2. Use a grounded wrist strap before handling computer components. If you do not have
one, touch both of your hands to a safely grounded object or to a metal object, such as
the power supply case.
3. Hold components by the edges and try not touch the IC chips, leads or connectors, or
other components.
4. Place components on a grounded antistatic pad or on the bag that came with the
components whenever the components are separated from the system.
5. Ensure that the ATX power supply is switched off before you plug in or remove the ATX
ower connector on the motherboard.
If the motherboard has mounting holes, but they don’t line up with the holes on the base and there
are no slots to attach the spacers, do not become alarmed you can still attach the spacers to the
mounting holes. Just cut the bottom portion of the spacers (the spacer may be a little hard to cut off, so
be careful of your hands). In this way you can still attach the motherboard to the base without worrying
about short circuits. Sometimes you may need to use the plastic springs to isolate the screw from the
motherboard PCB surface, because the circuit wire may be near by the hole. Be careful, don't let the
screw contact any printed circuit write or parts on the PCB that are near the fixing hole, otherwise it may
damage the board or cause board malfunctioning.
Installing the motherboard to the chassis…
þ The GA-8GE800 Pro motherboard o 2 Port USB Cable x 1
þ IDE cable x 1/ Floppy cable x 1 þ 2 Port USB Cable x 2
þ CD for motherboard driver & utility þ SPDIF-KIT x 1 (SPDIF Out KIT)
þ GA-8GE800 Pro user's manual þ IEEE 1394 Cable x1
þ I/O Shield o Audio Combo Kit x 1
þ Quick PC Installation Guide (SURROUND-Kit + SPDIF Out KIT)
o RAID Manual þ Motherboard Settings Label
