- 17 - Hardware Installation Process
English
12) COMB (COM B Connector)
Be careful with the polarity of the COMB connector. Check the pin assignm ent while you connect
the COMB cable. Please contact your nearest dealer for optional COMB cable.
Pin No. Definition
1 NDCDB-
2 NSINB
3 NSOUTB
4 NDTRB-
5 GND
6 NDSRB-
7 NRTSB-
8 NCTSB-
9 NRIB-
10 No Pin
1 9
10
2
