- 32 -8VM533M-RZ Series Motherboard
English
Exit Without Saving
Type "Y" will quit the Setup Utility without saving to RTC CMOS.
Type "N" will return to Setup Utility.
Save & Exit Setup
Type "Y" will quit the Setup Utility and save the user setup value to RTC CMOS.
Type "N" will return to Setup Utility.
CMOS Setup Ut ility-Co pyright (C) 1984 -2003 Aw ard Soft ware
} Stan dard CM OS Feat ures
} Adva nced BI OS Feat ures
} Inte grated Periphe rals
} Powe r Manag ement S etup
} PnP/ PCI Con figurat ions
} PC H ealth St atus
} Frequ ency/Vol tage Con trol
Load Fail-Sa fe Defa ults
Load Optimiz ed Defa ults
Set Supervis or Pass word
Set U ser Pass word
Save & Exit S etup
Exit Without S aving
ESC: Quit higf: Selec t Item
F8: Q- Flash F10: Save & Exit S etup
Aban don all Data
Quit Without S aving (Y/ N)? N
CMOS Setup Ut ility-Co pyright (C) 1984 -2003 Aw ard Soft ware
} Stan dard CM OS Feat ures
} Adva nced BI OS Feat ures
} Inte grated Periphe rals
} Powe r Manag ement S etup
} PnP/ PCI Con figurat ions
} PC H ealth St atus
} Frequ ency/Vol tage Con trol
Load Fail-Sa fe Defa ults
Load Optimiz ed Defa ults
Set Supervis or Pass word
Set U ser Pass word
Save & Exit S etup
Exit Without S aving
ESC: Quit higf: Selec t Item
F8: Q- Flash F10: Save & Exit S etup
Save Data to CMOS
Save to CMOS an d EXIT (Y/ N)? Y
