- 23 - BIOS Setup
English
Advanced BIOS Features
First / Second / Third Boot Device
Floppy Select your boot device priority by Floppy.
LS120 Select your boot device priority by LS120.
HDD-0~3 Select your boot device priority by HDD-0~3.
SCSI Select your boot device priority by SCSI.
CDROM Select your boot device priority by CDROM.
ZIP Select your boot device priority by ZIP.
USB-FDD Select your boot device priority by USB-FDD.
USB-ZIP Select your boot device priority by USB-ZIP.
USB-CDROM Select your boot device priority by USB-CDROM.
USB-HDD Select your boot device priority by USB-HDD.
LAN Select your boot device priority by LAN.
Disabled Select your boot device priority by Disabled.
Password Check
System The system can not boot and can not access to Setup page will be denied if the
correct password is not entered at the prompt.
Setup The system will boot, but access to Setup will be denied if the correct password
is not entered at the prompt. (Default v alue)
CPU Hyper-Threading
Enabled Enables CPU Hyper Threading Feature. Please note that this feature is only working
for operating system with multi processors mode supported. (Default value)
Disabled Disables CPU Hy per Threading.
" # " System will detect automatically and show up when you install the Intel
®
Pentium
®
4
processor w ith HT Technology.
CMOS Setup Ut ility-Co pyright (C) 1984 -2003 Aw ard Soft ware
Adva nced BI OS Feat ures
Firs t Boot D evice [Flo ppy]
Seco nd Boot D evice [HDD -0]
Thir d Boot D evice [CDR OM]
Pas sword C heck [Set up]
CPU H yper-Threa ding
#
[Enab led]
higf: M ove Enter: Select +/-/ PU/PD: V alue F10: Save ESC: Exit F1: General Help
F5: P revious V alues F6: Fa il-Safe De fault F7: Optimiz ed Defa ults
Item Help
Menu L evel}
Selec t Boot D evice
prio rity
[Flo ppy]
Boot from fl oppy
[LS1 20]
Boot from L S120
[HDD -0]
Boot from Firs t HDD
[HDD -1]
Boot from Secon d HDD
