Chapter 11 Description of Parameter SettingsAFE2000 Series
11-98
Password for Communication Card (Low word)
Password for Communication Card (High word)
Factory Setting: 0
Settings 0~255
Communication Card Reset
Factory Setting: 0
Settings
0: No function
1: Reset (Returns to factory setting.)
Communication Card Additional Setting
Factory Setting: 1
Settings
Bit0: Enable IP filter
Bit 1: Enable to write internet parameters (1bit). This bit will change to disable when it
finishes saving the internet parameter updates.
Bit 2: Enable login password (1bit). This bit will change to disable when it finishes
saving the internet parameter updates.
Communication Card Status
Factory Setting: 0
Settings
Bit 0: password enable
When the communication card is set with password, this bit is enabled. When the
password is cleared, this bit is disabled.
