Chapter 11 Description of Parameter SettingsAFE2000 Series
11-81
(NC).
7
Drive / Regenerate
When AFE2000 is at Drive status, the contact is closed (NC).
8
Fault Reset
When AFE2000 fault is cleared and receives a reset
command, the contact will be closed (NC) for 100ms.
Multi-Function Output Direction
Factory Setting: 0
Settings 0~65535
This function is for bit setting. Bit =1 indicate the multi-function output is in a reverse direction. For
example: Pr.02-11 =1 (operating indicator), when forward direction ouput bit is set to 0, Relay 1
will be ON when the drive is operating and Relay 1 will be OFF when the drive stops. Conversely,
if reverse direction output bit is set to 1, Relay 1 will OFF when the drive is operating and Relay 1
will be ON when the drive stops.
Bit 3 Bit 2 Bit 1 Bit 0
MO2 MO1 MRA RA
