Chapter 10 Summary of Parameter SettingsAFE2000 Series
10-71
Parameter Explanation Settings
Factory
Setting
Address 2
04-24 Communication Card IP
Address 3
0~255 0
04-25 Communication Card IP
Address 4
0~255 0
04-26 Communication Card
Address Mask 1
0~255 0
04-27 Communication Card
Address Mask 2
0~255 0
04-28 Communication Card
Address Mask 3
0~255 0
04-29 Communication Card
Address Mask 4
0~255 0
04-30 Getway Address 1 of the
Communication Card
0~255 0
04-31 Getway Address 2 of the
Communication Card
0~255 0
04-32 Getway Address 3 of the
Communication Card
0~255 0
04-33 Getway Address 4 of the
Communication Card
0~255 0
04-34 Password for Communication
Card (Low word)
0~255 0
04-35 Password for Communication
Card (High word)
0~255 0
04-36
Communication Card Reset
0: No function
1: Reset (Returns to factory setting.)
0
04-37
Communication Card
Additional Setting
Bit0: Enable IP filter
Bit 1: Enable to write internet parameters (1bit).
This bit will change to disable when it finishes
saving the internet parameter updates.
Bit 2: Enable login password (1bit). This bit will
change to disable when it finishes saving the
internet parameter updates.
0
04-38
Communication Card Status
Bit 0: password enable
When the communication card is set with
password, this bit is enabled. When the password
is cleared, this bit is disabled.
0
