Bosch GOP 12V-28 [19/301] Fitting changing the application tool

Application tool Material Application

HCS multi blade Roofing felt, carpets, arti-

ficial turf, cardboard, PVC

flooring

Fast and precise cutting of soft material and flexible abras-

ive materials;

example: Cutting carpets, cardboard, PVC flooring, roof-

ing felt, etc.

Scraper, fixed Carpets, mortar, con-

crete, tile adhesive

Scraping on a hard surface;

example: Removing mortar, tile adhesive, concrete

residue and carpet adhesive residue

Scraper, flexible Carpet adhesive, paint

residue, silicone

Flexible scraping on a soft surface;

example: Removing silicone joints, carpet adhesive

residue and paint residue

Bi-metal segment

serrated blade

Insulation material, insula-

tion boards, floor panels,

impact sound insulation

boards, cardboard, car-

pets, rubber, leather

Precise cutting of soft materials;

example: Cutting insulation boards to size, cutting pro-

truding insulation material to length so that it is flush with

the surface

TC-Riff sanding fin-

ger

Wood, paint Sanding of wood or paint in hard-to-reach areas without

sanding paper;

example: Sanding off paint between window shutter slats,

sanding wooden flooring in corners

TC-Riff plunge cut

saw blade

Fibreglass, mortar, wood Plunge cuts in extremely abrasive materials;

example: Routing of thin mosaic tiles

HCS universal joint

cutter

Expansion joints, window

putty, insulation materials

(rock wool)

Cutting soft materials;

example: Cutting silicone expansion joints or window

putty

Fitting/changing the application tool

Remove the application tool if one has already been fitted.

To remove the application tool, use the hex key (12) to

loosen the clamping bolt(11) and remove the tool.

Position the required application tool (e.g. plunge cut saw

blade (10)) on the tool holder (7) so that the depressed

centre is facing downwards (see figure on the graphics page,

text on the application tool should be legible from above).

Turn the application tool to a position which is convenient

for the job at hand and allow it to lock into place in the cams

of the tool holder (7). Twelve positions offset by 30° are

possible for this.

Secure the application tool using the bolt(11). Tighten the

bolt using the hex key(12) until the rounded head of the bolt

is lying flat against the application tool.

u Check that the application tool is seated securely. Ap-

plication tools that are attached incorrectly or are not se-

curely fixed in place may come loose during operation,

thereby putting you at risk.

Selecting a sanding sheet

Different sanding sheets are available, depending on the material you are working with and the required surface removal rate:

Sanding sheet Material Application Grit

– All wood and wood-based

materials (e.g. hardwood,

softwood, chipboard, con-

struction boards)

– Metal materials

For pre-sanding, e.g. of rough and uneven beams and

boards

Coarse 40

For surface sanding and levelling of slight irregularities Medium 80

100

120

For finish-sanding and fine sanding of wood Fine 180

240

320

400

English | 19

Bosch Power Tools 1 609 92A 4A6 | (11.06.2018)
