零件号码 零件名( 件数 备注 零件号码 零件名( 件数 备注
Parts No. Name of Parts
QTY Parts No. QTY Remarks
5100120100
上轴
-----------------
Main Shaft------------------------------
1 XB106001
油棉
-----------------
Roller Felt-------------------------
1
5100120500 后套油盖组件-----
Oil Seal---------------------------------
1 ZME05001 螺丝-----------------
Screw (M5-0.8×9.3)-------------
2
51001208L0 凸轮曲柄-----------
Counter Weight------------------------
1 ZSA15010 螺丝-----------------
Screw (15/64-28×13)------------
2
51001220H4
偏心轮
--------------
Feed Drive Eccentric Cam-----------
1 ZSA15037
螺丝
-----------------
Screw (15/64-28×8.5)-----------
1
51001213L0 针棒连接轴--------
Needle Bar Crank---------------------
1 ZSA16025 螺丝-----------------
Screw (1/4-40×6)----------------
4
5100122100 偏心轮盖板--------
Thrust Collar---------------------------
1 ZSA18002 螺丝-----------------
Screw (9/32-28×11.5)-----------
1
5100122600 固定环--------------
Thrust Collar Asm---------------------
1 ZSB09014 螺丝-----------------
Screw (9/64-40×6)---------------
2
51001901L6 天秤组件-----------
Thread Take-up Complete-----------
1 ZSB11076 螺丝-----------------
Screw (11/64-40×12)------------
2
5100190500 挡油环--------------
Rubber----------------------------------
1 ZSB16031 螺丝-----------------
Screw (1/4-40×11)---------------
2
5100192000 天秤架--------------
Lever------------------------------------
1 ZSB18011 螺丝-----------------
Screw (9/32-28×11)-------------
1
5100192200 销油线--------------
Oil Thread------------------------------
1 ZSK09005 螺丝-----------------
Screw (9/64-40×6)---------------
1
5100354200 油量调节销--------
Oil Amount Adjusting Pin-----------
1
5100354300 调节销圈-----------
Oil Adjusting Collar------------------
1
51006020T5
定位磁盘组件
-----
Dynamo Stator-------------------------
1
51001204T0 上轴后套-----------
Main Shaft Bushing,Rear-------------
1
51001223T5
上轮组件
-----------
Flywheel Asm--------------------------
1
51006024T5 磁铁台(A)----------
Magnet Fitting Base A Asm---------
1
51006024T6 磁铁台(B)----------
Magnet Fitting Base B Asm---------
1
51006027T0
磁铁
(C)-------------
Magnet C-------------------------------
1
BN081208 滚针轴承-----------
Roller Bearing-------------------------
2
FD1061-0A 天秤固定销-------- Thread Take-up Crank Shaft Asm------- 1
FD1067-0D 针棒连接杆--------
Needle Bar Crank Rod----------------
1
FD1101-0A 上轴前套-----------
Front Bushing -------------------------
1
FD1102-0A 上轴中套-----------
Intermediate Bushing ----------------
1
FD1103-0A 中套接头-----------
Joint-------------------------------------
1
OPP0029178 O型圈---------------
Rubber Ring----------------------------
1
OPP0044240 定位O型圈---------
Rubber Ring----------------------------
1
RB200200 挡圈-----------------
Snap Ring-------------------------------
1
RU010100 扎带-----------------
Clip--------------------------------------
1
WA049003 垫圈-----------------
Washer----------------------------------
2
1.CS-7500-5/7500HLN-BT 系列 上轴挑线机构 MAIN SHAFT THREAD TAKE-UP LEVER MECHANISM
Remarks
Name of Parts
3
G
O
L
D
E
N
W
H
E
E
L
