零件号码 零件名( 件数 备注 零件号码 零件名( 件数 备注
Parts No. Name of Parts
QTY Parts No. QTY Remarks
BNBK091310
滚针轴承
-----------
Roller Bearing-------------------------
1
FD1072-0A 针杆摆动轴--------
Needle Rod Rocking Base Shaft----
1
FD1073-0D 针杆摆动架--------
Bracket----------------------------------
1
FD1081-0A
摆动导轨
-----------
Slide Block Guide---------------------
1
FD1340-0A 针送料轴-----------
Connecting Shaft----------------------
1
FD1341-0A 前轴套--------------
Rock Shaft Bushing Front------------
1
FD1342-0A 固定环--------------
Thrust Collar Asm---------------------
2
FD1343-0A 后轴套--------------
Rock Shaft Bushing Rear-------------
1
FD1345-0A 前曲柄--------------
Driving Crank Front------------------
1
FD1346-0A 驱动杆--------------
Driving Link---------------------------
1
FD1347-0A 驱动销--------------
Needle Bar Link Pin------------------
2
FD1348-0A 后曲柄--------------
Shaft Arm Asm (Rear)----------------
1
FD1349-0A 连接杆--------------
Connecting Rod------------------------
1
FD1350-0A 连接杆销-----------
Connecting Rod Shaft----------------
1
FD1352-0D 摆动架导向块-----
Needle Bar Frame Guide-------------
1
FD1353-0A
摆动架轴套
--------
Bushing---------------------------------
1
WA069001 垫圈-----------------
Washer----------------------------------
1
ZSA11025 螺丝-----------------
Screw (11/64-40×2.7)-----------------
1
ZSA12010
螺丝
-----------------
Screw (3/16-28×7)--------------------
2
ZSA16012 螺丝-----------------
Screw (1/4-40×4)----------------------
4
ZSB09007 螺丝-----------------
Screw (9/64-40×7.5)------------------
2
ZSB09090 螺丝-----------------
Screw (9/64-40×3.8)------------------
2
ZSB11069 螺丝-----------------
Screw (11/64-40×5)-------------------
1
ZSB12002 螺丝-----------------
Screw (3/16-28×12)-------------------
1
ZSB12012 螺丝-----------------
Screw (3/16-28×15)-------------------
1
ZSB12063
螺丝
-----------------
Screw (3/16-28×14)-------------------
1
ZSG15085 螺丝-----------------
Screw (15/64-28×7.5)-----------------
1
ZSL15002 螺帽-----------------
Nut(15/64-28)--------------------------
1
ZSL15004
螺帽
-----------------
Nut(15/64-28)--------------------------
1
2.CS-7500-5/7500HLN-BT 系列 针送料机构 NEEDLE FEED MECHANISM
Remarks
Name of Parts
5
G
O
L
D
E
N
W
H
E
E
L
