6
EN
Instruction manual
PART LIST
1. Front handle
2. Wing screw for belt adjuster
3. Drive belt cover
4. On/Off switch
5. Lock-on button
6. Dust extraction outlet
7. Rear handle
8. Carbon brush housing
9. Speed selector thumbwheel
10. Tension lever
11. Dust bag
12. Sanding belt
CONTENT OF THE BOX
Instruction manual (1 pc), dust bag (1 pc), sanding belt
(1 pc).
INTENDED USE
This model of belt sander is intended for dry sanding
only.
SAFETY REGULATION FOR THE USE
General safety rules
The following listed safety instructions should serve you
for the right use of the tool and for the protection of your
own safety, therefore, please read this very carefully.
When passing this tool to a third person, these
instructions must be handed too.
Retain this user’s manual and all other literature supplied
with your tool for any future reference.
Comply with all the safety information and the warnings
on the tool.
Be familiar with the controls and the proper use of the
tool before attempting to use it and above all, make sure
you know how to stop to use it in case of emergency.
Following these simple instructions will also maintain
your tool in good working order.
∙ The tool must be assembled correctly before use.
∙ Only use the tool for its designed purposes.
∙ On the tool, there may be also decals and further
indications about the safety equipment to use that
must be considered. The prevention of accidents is
dependent upon the awareness, common sense and
proper training of everyone involved in the operation,
transport, maintenance and storage of the tool.
∙ Never leave the tool unattended.
∙ Never allow children to use the tool. Children
should be supervised to ensure that they do not play
with the tool.
∙ Keep children and pets away. All onlookers should
be kept at a safe distance away from the tool when it
is in use.
∙ The user is responsible for third parties while
working with the tool.
∙ People who aren’t acquainted with the operating
instructions, children, juveniles who have not yet
reached the minimum age for using this tool and people
under the inuence of alcohol, drugs or medication
are not allowed to use the tool. Local regulations may
restrict the age of the operator.
WARNING! The consumption of
alcohol, medication and drugs, plus
states of illness, fever and fatigue will
affect your ability to react. Do not use
this tool in any of these situations.
∙ Make sure that all the protective devices (if present)
are tted and are in good condition.
∙ Never operate the tool with defective safety devices
or guards (if present), or without safety devices in
place.
TOOL SPECIFICATIONS
Model BS-1010G
Voltage ~ Frequency [V ~ Hz] 230 ~ 50
Rated power [W] 1010
No-load speed [m/min] 120 - 380
Sanding surface size [mm] 76 x 533
Sound pressure level [dB(A)] 89.7 (K=3)
Sound power level [dB(A)] 100.7 (K=3)
Vibration level [m/s
2
] 5.1 (K=1.5)
Weight [kg] 3.6
Safety class II
