ADJUST TV PICTURE
Press Menu key on unit or remote control. Menu will be displayed on screen. Press VOL+ or VOL to
enter PICTURE submenu. Then press CH+ or CH key to select submenu.
CONTRAST > BRIGHT > COLOR > TINT > SHARPNESS
When you select one of the above submenu , press VOL+ or VOL key to change its setting. Pressing
VOL+ will increase the setting and green bar will move to right. Pressing VOL will decrease the setting
and green bar will move to left.
Press Picture key on remote control to enter standard TV picture setting menu:
SOFT > PERSONAL > DYNAMIC
SWITCH OF TV SYSTEM
Press CH+ or CH key on remote control to select SYSTEM in menu. Press VOL+ or VOL to enter the
submenu. Then press CH+ or CH key to select COLOR SYSTEM and SOUND SYSTEM. Note: When TV
is in AV mode, only COLOR SYSTEM can be selected. Pressing COL SYS key and SOUND SYS key locat
ed on remote control will directly enter COLOR SYSTEM and SOUND SYSTEM setting menu.
1. Press CH+ or CH to select submenu COLOR SYSTEM. Press VOL+ or VOL key to select the TV sig
nal system: PAL > NTSC358 > NTSC443 > AUTO. When AUTO is selected, the unit will automatically
select the COLOR SYSTEM and display the correct picture.
2. Press CH+ or CH key to select submenu SOUND SYSTEM. Press VOL+ or VOL key to select TV
SOUND SYSTEM: BG > DK > I > M > BGSUB. Only when you select the correct SOUND SYSTEM, the
sound will be clear without any noise.
TIMER SETTING
Press CH+ or CH key to enter TIMER setting . Press VOL+ or VOL key to enter submenu. Then press
CH+ or CH key to select following:
CLOCK > ON CH. > ON TIMER
1. Select submenu CLOCK and press VOL+ to enter AM/FM setting. Press the number keys on remote
control to input time. The turn of inputting is as follows:
Hour 10digit > Hour 1digit > Min.10digit > Min.1digit > Set Completion
2. After selecting submenu ON CH, press the number keys to input Channel No.. Pressing VOL+ or
VOL will select Channel No. setting in turn.
3. After the selection of submenu ON TIMER, press VOL+ to enter AM/FM setting. Press number
keys on remote control to input time as follows:
Hour 10digit > Hour 1digit > Min.10digit > Min.1digit > Set Completion
4. When power is cutoff or the unit is turned off, the above time setting will be invalid. When the unit
is standby, the above setting is valid.
CHANNEL PRESET
Select PRESET under main menu by pressing CH+ or CH key. Press VOL+ or VOL to enter submenu.
Then press CH+ or CH key to select the item under submenu as follows:
AUTO PROGRAM > AREA > SKIP CH > CH NO.
1. After the selection of submenu CH NO., press number keys on remote control to input Channel No..
Or simply press VOL+/VOL to select channel.
2. When you want to delete one channel, you can select the Channel No. and press VOL+ or VOL key to
select SKIP CH/ SKIP. After that, this channel will not be shown when you use PR+/PR or CH+/CH to
select channel.
3. When you select submenu AREA, you may press VOL+ or VOL key to choose local TV network circu
8 13
РУССКИЙENGLISH
КНОПКИ НАЗНАЧЕНИЯ
1. Кнопка "Вкл./Выкл".
2. ЖК индикатор питания.
3. Сенсор сигнала ДУ.
4. Кнопка переключения на предыдущий канал
(CH).
5. Кнопка переключения на следующий канал
(CH+).
6. Снизить громкость (VOL).
7. Прибавить громкость (VOL+).
8. Кнопка выхода в "Меню".
9. Кнопка переключения в режим ожидания.
10. Переключатель TV/AV (ТВ/Аудиовидео).
11. Гнездо подключения наушников.
12. Гнездо входа видеосигнала.
13. Гнездо входа звукового сигнала.
14. Антенна.
15. Гнездо подключения внешней антенны.
16. Входное гнездо постоянного тока.
17. Входное гнездо переменного тока.
ПУЛЬТ ДИСТАНЦИОННОГО УПРАВЛЕНИЯ
Расположение кнопок
1. Кнопка "Вкл./Выкл" (Power).
2. Приглушение звука.
3. Кнопка "Display".
4. Кнопка выхода в "Меню".
5. Переключатель режима TV/AV.
6. Таймер сна.
7. Кнопка выбора звуковой системы.
8. Кнопка функции "Loop".
9. Следующий канал (CH+).
10. Предыдущий канал (CH).
11. Прибавить громкость (VOL+).
12. Снизить громкость (VOL).
13. Кнопка выбора системы цветов.
14. Настройка картинки.
15. Номерные кнопки.
VT-1011.qxd 30.10.03 14:48 Page 16
